High-Reliability Integrated Navigation System-Low-Power Consumption MEMS Measurement Unit
  • name
  • name
  • name
  • name

High-Reliability Integrated Navigation System-Low-Power Consumption MEMS Measurement Unit

MOQ: 1
Standard Packaging: 30cm*30cm*28cm
Delivery Period: 14days
Payment Method: T/T
Supply Capacity: 50/1day
Details Information
Product Description
Detail Information
Place of Origin
WUHAN
Brand Name
CSSC
Certification
TED298025250
Model Number
DP-MS1AA
Usage:
Position Sensor,Vibration Sensor,Inertial Navigation,inertial Sensor,Speed Sensor
Output:
Digital Sensor,Analog Sensor,Other,INS,inertial Sensor
Theory:
Capacitance Sensor,Other,Optical Sensor,Current Sensor,GPS Navigation
Type:
Gps Navigator,Inertial Navigation System,Gps Tracker
Product Name:
Inertial Navigation Systems,Compass Sensors,Accelerometer,INS,Fiber Optic Gyros
Material:
Metal,Zinc,MEMS,300 Series Stainless Steel
Name:
Mini AHRS 3000 Attitude Heading Reference System,IMU300 High Accuracy Digital IMU,High Accuracy Strapdown MEMS INS Inertial Navigation Systems
Wide Operating Temperature:
-40~+85℃
Product Description
Performance Specifications


Parameter(Typical Values) Unit DP-MS1AA
Gyroscope Measurement Range °/s ±400
Bias Offset °/h 15
Bias Instability (Allan Variance) °/h 0.3
Bias Stability (10 s smoothing, 1σ, room temp) °/h 3
Bias over Full Temperature Range °/h 20
Bias Repeatability °/h 3
Angle Random Walk High-Reliability Integrated Navigation System-Low-Power Consumption MEMS Measurement Unit 0°/ 0.15
Scale Factor Nonlinearity ppm 100
Scale Factor Repeatability ppm 100
Bandwidth Hz 250
Cross Coupling % 0.1
Accelerometer Measurement Range g ±80
Bias Stability (10 s smoothing, 1σ, room temp) mg 1
Bias Variation over Temperature mg 0.5
Bias Repeatability mg 5
Scale Factor Repeatability ppm 500
Bandwidth Hz 100
Cross Coupling % 0.1
Start-up Stabilization Time s 1
Data Update Rate Hz 1000
Operating Voltage V 5±0.5
Steady-state Power Consumption W 1.5
Operating Temperature ℃ -45~80
Dimensions mm 44.8×38.6×20
Weight g 52±5
Start-up Stabilization Time
RS-422




High-Reliability Integrated Navigation System-Low-Power Consumption MEMS Measurement Unit 1
